Thinking. Ahead. In Neurotechnology and beyond.

We are providing tomorrow's solutions in neurotechnology already today. In every project, our goal is to exceed customer expectations and to make the impossible possible.

Who we are.

CorTec was founded in September 2010 and in the summer of 2018 we moved into new premises near the Airport Campus of the University of Freiburg with our own cleanroom facilities.

As a medical technology company, our vision is to become the development & manufacturing partner of choice for implantable technologies, empowering our customers to shape the future of medical innovations.

We help our customers to realize their innovations for medical devices. With over 10 years of experience within the field of medical device development we are their partner from the idea to the finished product.

What we stand for.

Our Mission

As a competent partner for our customers’ medical device development and manufacturing, we maintain the highest standards in engineering, production, quality and regulatory compliance.

Our highly experienced teams dedicate their engineering passion to accompany every step of their product lifecycle journey, from concept to commercialization. In every project, our goal is to exeed customer expectations and to make the impossible possible.

Our Vision

We are the Development & Manufacturing Partner of choice for implantable technologies, empowering our customers to shape the future of medical innovations.

cortec_kompass

Team

Great ideas require a strong team that is working closely together. Learn more about our team, our management and our advisory boards.

Quality

We have to meet the highest standards in everything that we do. Learn more about our Quality Management System and our certifications.

Investor Relations

In cooperation with our investors we work on the future success of our developments and on our further corporate growth.

Get a Quote

We’re happy to help you realize your next project. Whether it is a complete implantable system design, an electrode or another component.

Please fill out the form below and our sales team will be in contact with you shortly.

SPECIFICATIONS

FEATURE

Recording channels

Sampling rate

Sampling dynamic range

High pass filter cut-off

Low pass filter cut-off

Amplifier band pass gain

Band pass roll-off

Reference


Stimulation

Stimulation channels

Current

Current source

Pulse width

Power supply

Wireless data transmission

Closed Loop latency

VALUE

32

1 kHz

16 bit (74 nV smallest increment)

ca. 2 Hz

325 Hz

Adjustable: 100-750

20 dB/dec

Any (subset) of the recording channels selectable by software or one dedicated hard-wired additional contact

Current-controlled, biphasic, rectangular, asymmetric stimulus pulses (cathodic amplitude with pulse width followed by an anodic counter pulse of 1/4x amplitude and 4x pulse width)

 32

Max. -6 mA / +1.5 mA (24 µA increments) within

 compliance voltage range of -11 V to +5 V

Can be directed to any of the 32 electrode contacts

Negative phase: 10 µs – 2,500 µs

Wireless inductive, 120-140 kHz

Bi-directional, radio frequency in 2400-2483.5 MHz band ≤ 40 ms
