SPECIFICATIONS

FEATURE

Recording channels

Sampling rate

Sampling dynamic range

High pass filter cut-off

Low pass filter cut-off

Amplifier band pass gain

Band pass roll-off

Reference


Stimulation

Stimulation channels

Current

Current source

Pulse width

Power supply

Wireless data transmission

Closed Loop latency

VALUE

32

1 kHz

16 bit (74 nV smallest increment)

ca. 2 Hz

325 Hz

Adjustable: 100-750

20 dB/dec

Any (subset) of the recording channels selectable by software or one dedicated hard-wired additional contact

Current-controlled, biphasic, rectangular, asymmetric stimulus pulses (cathodic amplitude with pulse width followed by an anodic counter pulse of 1/4x amplitude and 4x pulse width)

 32

Max. -6 mA / +1.5 mA (24 µA increments) within

 compliance voltage range of -11 V to +5 V

Can be directed to any of the 32 electrode contacts

Negative phase: 10 µs – 2,500 µs

Wireless inductive, 120-140 kHz

Bi-directional, radio frequency in 2400-2483.5 MHz band ≤ 40 ms
