Relax and learn! The vagus nerve also supports motor learning.

AirRay Sling Cuff electrode wrapped around fingers - CorTec GmbH

The vagus nerve is the major constituent of the parasympathetic nervous system. Together with the antagonistic sympathetic system, it forms the autonomic nervous system, which regulates lots of reflexes and organ functions. The vagus is usually associated with “rest and digest” or “feed and breed” type of behaviors, as opposed to the ”fight or flight” functions of the sympathetic system.

The general calming effects of vagus nerve activity are being explored in several neuromodulation strategies, for example, for lowering blood pressure, soothing epilepsy, or overcoming depression.

Apart from these generalized calming functions, though, new work is beginning to show that the nerve also contributes to higher brain functions. Indeed, the nerve carries both, fibers that travel from the brain to peripheral organs, as well as ones from the periphery to the brain. So, it actually serves very much as a bidirectional interface between the body and the brain.

And this interface may be involved in complicated information processing tasks, as a research group in Colorado, USA, has found out. The authors have used CorTec micro sling cuff electrodes to stimulate the vagus nerve in awake behaving mice. The animals were trained in a motor task to use their right forepaws to extract a food pellet from an opening in a plexiglass training box.

What they found is astonishing: When the vagus nerve was stimulated immediately after a successful reaching movement (as opposed to other times), motor skill learning was significantly improved. Concurrently, vagus nerve stimulation seemed to alter the neutral coding in a specific neural population in the motor cortex of the population across the entire reach. Using a plethora of advanced neuroscience research techniques, including optogenetics and calcium imaging, the authors were able to pinpoint the motor learning improvement effect to a cholinergic neural pathway activity arising from the basal forebrain.

These results open up a whole new field of possible applications for vagus nerve neuromodulation. Boosting motor learning for rehabilitation purposes, e.g. after stroke, is only one of them.



Citation:

Bowles S, Hickman J, Peng X, Williamson WR, Huang R, Washington K, Donegan D, Welle CG. Vagus nerve stimulation drives selective circuit modulation through cholinergic reinforcement. Neuron. 2022 Sep 7;110(17):2867-2885.e7. doi: 10.1016/j.neuron.2022.06.017. Epub 2022 Jul 19. PMID: 35858623.





More details about our Cuff Electrode Technology

We are providing bidirectional interfaces to the peripheral nervous system with our cuff electrodes. No matter what diameter and which specific functionality is needed. We are helping you to determine the best cuff electrode for your individual case. From research to medical device design. Reach out to our Sales Team and get in contact!

More User Stories using our implant technology

Discover more User Stories and read about novel research approaches, new devices and awesome scientific achievements. Visit our Story section “User Stories”.

Further readings in User Stories:

The Brain Interchange System for Stroke Rehabilitation

We are again featured in the latest edition of Open Access Government  – more specifically...

A Software Interface for Developing Next Generation Neurotherapies

Closed-Loop Platform for Neurotherapy – NIH-funded Project for Stroke Rehabilitation   The first “brain pacemakers”,...
brain computer interface illustration human brain

Neuroprosthetics review highlights need for new hardware

A group of authors from the University of Bordeaux has assessed the state of the...

A promising bioelectronics target in our neck

The carotid bodies are small glands sitting in the bifurcation of the carotid arteries (which...

Contact

Do you have any questions regarding our Company, our Products or our Technology?
We are happy to receive your message!

Get a Quote

We’re happy to help you realize your next project. Whether it is a complete implantable system design, an electrode or another component.

Please fill out the form below and our sales team will be in contact with you shortly.

SPECIFICATIONS

FEATURE

Recording channels

Sampling rate

Sampling dynamic range

High pass filter cut-off

Low pass filter cut-off

Amplifier band pass gain

Band pass roll-off

Reference


Stimulation

Stimulation channels

Current

Current source

Pulse width

Power supply

Wireless data transmission

Closed Loop latency

VALUE

32

1 kHz

16 bit (74 nV smallest increment)

ca. 2 Hz

325 Hz

Adjustable: 100-750

20 dB/dec

Any (subset) of the recording channels selectable by software or one dedicated hard-wired additional contact

Current-controlled, biphasic, rectangular, asymmetric stimulus pulses (cathodic amplitude with pulse width followed by an anodic counter pulse of 1/4x amplitude and 4x pulse width)

 32

Max. -6 mA / +1.5 mA (24 µA increments) within

 compliance voltage range of -11 V to +5 V

Can be directed to any of the 32 electrode contacts

Negative phase: 10 µs – 2,500 µs

Wireless inductive, 120-140 kHz

Bi-directional, radio frequency in 2400-2483.5 MHz band ≤ 40 ms
