The Brain Interchange System for Stroke Rehabilitation

We are again featured in the latest edition of Open Access Government  – more specifically our Brain Interchange System and our way to Stroke Rehabilitation.

Our Goal: enhancing the plasticity and enabling the patient to recover after a stroke. One method to achieve the enhancement of plasticity is electrical stimulation of the brain. Fundamental studies already demonstrated the effectiveness of this mechanism successfully. The therapeutic success of conventional therapy is expected to be substantially improved when the plasticity is enhanced.

Consequently, patients who do not benefit from conventional rehabilitation might be able to regain functions, and patients who are responding to conventional rehabilitation might improve or accelerate the results of their therapy.

To make this dream come true, a novel medical device for plasticity enhancement needs to be developed and built. We are tackling this exact mission to bring a device to market, from which stroke patients will benefit in the future.

To read the full article, follow the link below:

CorTec in Open Access Government



Further readings in Company and Technology:

A Software Interface for Developing Next Generation Neurotherapies

Closed-Loop Platform for Neurotherapy – NIH-funded Project for Stroke Rehabilitation   The first “brain pacemakers”,...
brain computer interface illustration human brain

Neuroprosthetics review highlights need for new hardware

A group of authors from the University of Bordeaux has assessed the state of the...

A promising bioelectronics target in our neck

The carotid bodies are small glands sitting in the bifurcation of the carotid arteries (which...
AirRay Sling Cuff electrode wrapped around fingers - CorTec GmbH

Relax and learn! The vagus nerve also supports motor learning.

The vagus nerve is the major constituent of the parasympathetic nervous system. Together with the...

Contact

Do you have any questions regarding our Company, our Products or our Technology?
We are happy to receive your message!

Get a Quote

We’re happy to help you realize your next project. Whether it is a complete implantable system design, an electrode or another component.

Please fill out the form below and our sales team will be in contact with you shortly.

SPECIFICATIONS

FEATURE

Recording channels

Sampling rate

Sampling dynamic range

High pass filter cut-off

Low pass filter cut-off

Amplifier band pass gain

Band pass roll-off

Reference


Stimulation

Stimulation channels

Current

Current source

Pulse width

Power supply

Wireless data transmission

Closed Loop latency

VALUE

32

1 kHz

16 bit (74 nV smallest increment)

ca. 2 Hz

325 Hz

Adjustable: 100-750

20 dB/dec

Any (subset) of the recording channels selectable by software or one dedicated hard-wired additional contact

Current-controlled, biphasic, rectangular, asymmetric stimulus pulses (cathodic amplitude with pulse width followed by an anodic counter pulse of 1/4x amplitude and 4x pulse width)

 32

Max. -6 mA / +1.5 mA (24 µA increments) within

 compliance voltage range of -11 V to +5 V

Can be directed to any of the 32 electrode contacts

Negative phase: 10 µs – 2,500 µs

Wireless inductive, 120-140 kHz

Bi-directional, radio frequency in 2400-2483.5 MHz band ≤ 40 ms
