Active Implantable Technologies – For Neuro & Beyond

We are your comprehensive partner for design, development, and manufacturing. With over 10 years of experience in clinical applications for implantables, we expedite your project timelines for faster market entry through quick turnarounds and unmatched support.

In every project, our goal is to exceed customer expectations and to make the impossible possible.

Our Products for your Medical Device

Based on your needs and individual requirements, we develop and manufacture implantable neurotechnological devices, components and sub-assemblies.

From Idea to Medical Device Manufacturing

We Support Your Project in Every Step of the Novel Therapy Discovery and Device Development Process.

Find jobs meant for you

Get a Quote

We’re happy to help you realize your next project. Whether it is a complete implantable system design, an electrode or another component.

Please fill out the form below and our sales team will be in contact with you shortly.

CorTec - Advanced Implantable Neurotechnology

One company. Two focused businesses.

CDMO · MedTech · Industry

Custom development & manufacturing for active implantable devices. Your partner from design to regulatory-ready product.

BCI · Future Vision · Clinical Research

Pioneering brain–computer interfaces that will redefine human potential. Explore the science, the vision, and the investment case.

SPECIFICATIONS

FEATURE

Recording channels

Sampling rate

Sampling dynamic range

High pass filter cut-off

Low pass filter cut-off

Amplifier band pass gain

Band pass roll-off

Reference


Stimulation

Stimulation channels

Current

Current source

Pulse width

Power supply

Wireless data transmission

Closed Loop latency

VALUE

32

1 kHz

16 bit (74 nV smallest increment)

ca. 2 Hz

325 Hz

Adjustable: 100-750

20 dB/dec

Any (subset) of the recording channels selectable by software or one dedicated hard-wired additional contact

Current-controlled, biphasic, rectangular, asymmetric stimulus pulses (cathodic amplitude with pulse width followed by an anodic counter pulse of 1/4x amplitude and 4x pulse width)

 32

Max. -6 mA / +1.5 mA (24 µA increments) within

 compliance voltage range of -11 V to +5 V

Can be directed to any of the 32 electrode contacts

Negative phase: 10 µs – 2,500 µs

Wireless inductive, 120-140 kHz

Bi-directional, radio frequency in 2400-2483.5 MHz band ≤ 40 ms
